FOTON 2tons crane truck, FOTON 4x2 right hand drive chassis, 5-shift manual gearbox, Quanchai 115HP diesel engine, XCMG 2 ton telescopic boom crane, cargo body dimension as optional, painting and logos depend on requirement.
Product Origin:
China CEECShipping Port:
China Main PortLead Time:
20 DaysPayment:
T/T, West Union
Applications:
FOTON 2 tons crane truck (also called XCMG boom crane, FOTON RHD crane truck, FOTON truck mounted crane, FOTON cargo truck with crane, telescopic boom crane truck, crane truck manufacturer) is used to lift the cargo, load, transport and unload heavy stuff.
There are telescopic boom cranes and knuckle boom cranes, covering a wide range of capacities as follows:
Telescopic Boom Crane: 2Ton, 3.2Ton, 4Ton, 5Ton, 6.3Ton, 8Ton, 10Ton, 12Ton, 14Ton, 16Ton, 25Ton
Knuckle Boom Crane: 1Ton, 2Ton, 3.2Ton, 4Ton, 5Ton, 6.3Ton, 8Ton, 10Ton, 12Ton, 14Ton, 16Ton, 25Ton, 50T, 100T
CEEC TRUCKS Cranes can be of famous brands as Palfinger (Canada), Unic (Japan), XCMG (China top brand), Zoomlion, etc.
Key Features:
---- FOTON chassis ensures perfect performance on driving
---- QUANCHAI technology engine, super powerful, no overhaul within 100,000 km.
---- High strength cargo body, nice shape and rational structure.
---- Easy operation and easy maintenance.
---- Premium cranes Palfinger (Canada), Unic (Japan), XCMG (China top brand), Zoomlion, etc.
Crane Features:
---- Single cylinder synchronization guy cable technology makes work efficiency much higher than before.
---- Advanced development means make sure that the design is very reliable.
---- The more symmetrical center design of pentagon & hexagon boom make it has bigger anti-bending capacity.
---- Compact hinge point design take up smaller space
---- The work is more safety after fitted over-winds alarm equipment.
---- The integer lifting winch improved the work efficiency greatly and prolonged work lift of hydraulic system.
---- Float three-point bridge structure design can lower the accessional stress on the chassis when traveling.
---- Self-designed & developed slewing machine with greater drive force can meet varied requirements of working situation.
---- Anti-slewing impulse equipment that make vehicle running safely
Specifications:
|
FOTON truck mounted crane (2 Tons boom crane) |
||
|
General |
Vehicle Brand |
CEEC |
|
Chassis Brand |
FOTON |
|
|
Overall Dimension |
5900 * 2500 * 3150 mm |
|
|
GVW / Kerb Weight |
10,500kg / 6,200kg |
|
|
Cab |
Cab Capacity |
2 persons allowed |
|
Air Conditioner |
Heating/cooling air conditioner |
|
|
Engine |
Fuel Type |
Diesel |
|
Engine Brand |
QUANCHAI |
|
|
Power |
115 HP |
|
|
Displacement |
2300 ml |
|
|
Emission Standard |
Euro 3 |
|
|
Chassis |
Drive Type |
4X2 Right hand drive |
|
Transmission |
5 speed levers with 1 reverse |
|
|
Wheelbase/No. of axle |
3300 mm / 2 |
|
|
Tire Specification |
7.00R16 |
|
|
Tire Number |
6 tires and 1 spare tire |
|
|
Max Speed |
90 km/h |
|
|
Paint |
Metallic paint |
|
|
Superstructure |
Cargo Box Dimension |
3600*2200*500 mm |
|
Crane Type |
Telescpoic boom crane |
|
|
Max Lifting Capacity |
2000 kg |
|
|
Slewing Angle |
360° All rotation |
|
|
Crane Weight |
950 kg |
|
|
Installation Space |
850 mm |
|
|
Control panel |
English or Your language |
|
|
All standard accessories: Basic tool kit, English manual…… |
||
|
Optional |
** Knuckle boom crane. ** Hydraulic tipper box. ** Box thickness according to requirement.
** Box height could be nominated |
|
Key words: Truck mounted crane, FOTON Crane truck, hydraulic boom crane vehicle
★ Euro 3 type, Quanchai engine, fuel consumption save 20%
★ Manual 5-shift mechanical transmission gearbox
★ 12 months fast moving spare parts for FREE★ Authorized FOTON crane trucks exporter
★ Training service for FOTON truck mounted crane.
China professional crane truck supplier and exporter, we supply high quality truck mounted crane. We can ensure the fast delivery time and 12 months guarantee for our crane trucks. Our crane trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, etc.
---- Maximize save your sea freight.
---- Professional guidance on your importing documents.
---- Safety, Quickly, Timely
---- Service more than 60 countries.
---- Professional guidance on your importing documents.
---- CO, FORM E, FORM P, Pre-shipping Inspection...
