The 5-ton flatbed wrecker upper body kits includes a hydraulic lifting device, a pallet, and a winch, primarily used for towing and clearing vehicles involved in traffic accidents.

The hydraulic lifting device allows for adjustable pallet angles, making towing more flexible. The pallet is a key component supporting the towed vehicle, ensuring its safety and stability. The winch is used to quickly remove the disabled vehicle and is electronically controlled, enhancing efficiency and safety.

The overall design of the flatbed wrecker upper body kits focuses on reliability, stability, and convenience, making it suitable for a variety of roadside rescue operations.

● China best flatbed wrecker upper body kits factory

● More than 30 years professional manufacturer experience.

● Be designed according to your requirements.

● Professional sales team which will help you to choose suitable truck.

● We can offer your a good after-sale service.

*5 ton flatbed wrecker upper body kits

road wrecker truck upper body*

CEEC factory is professional manufacturer in truck area,
guarantee all products Brand-New and High-Quality.

» Ⅰ.Product Defination and Introduction:

Manufacturer: CEEC TRUCKS INDUSTRY CO., LIMITED.

Product Features

●Hydraulically driven, it offers flexible and efficient operation.

●Sturdy construction and strong load-bearing capacity make it suitable for a wide range of vehicle types.

●Safe and reliable, equipped with a wire rope and tow hook for secure attachment.

●Highly adaptable, with an adjustable telescopic arm and pallet, it's suitable for complex rescue environments.

5 ton flatbed wrecker upper body kits (also called flatbed road rescue tow truck superstructure, road wrecker truck upper body, wrecker towing truck upper body kits, wrecker truck upper body, road block removal truck superstructure,etc.)  It is mainly used for road rescue, accident vehicle clearance, and towing of disabled vehicles. It can quickly remove broken down or accident vehicles from the road to ensure smooth traffic flow.

Hydraulic System: The road wrecker truck's upper body relies on a powerful hydraulic system.

●The hydraulic pump transmits power to drive the telescopic arm, trailer frame, and support legs, raising and lowering the telescopic arm and extending and retracting the towing frame.

●When a disabled vehicle needs to be towed, the hydraulic system adjusts the angle and length of the telescopic arm and precisely controls the position of the trailer frame, ensuring a stable pull of the vehicle onto the tow truck's bed or pallet.

Towing and securing: Flatbed wrecker upper body kits utilize a wire rope and tow hook for towing.

●The wire rope pulls the disabled vehicle via an electric drum or manual operation, while the tow hook secures the vehicle to the tow truck, ensuring safety and stability during towing.

●Hydraulically, the vehicle can be lifted or adjusted to ensure it is more convenient and safe to tow to the desired location.

» Ⅱ.Product Parameter for 5 ton flatbed wrecker upper body kits：



5 ton flatbed wrecker upper body kits
size	Flatbed: 4600x2200 mm
Standard configuration	5 tons winch 1 set, can lift 5tons
	Auxiliary wheel 2pcs
	with rear towing device
	Steel wire rope 21m
	Bundle belt :4pcs
	Rear tail lights LED,both sides electronic lights
	Tool box
Special performance	1.It can carry 1 car in the flatbed , haul one car by the rear towing device
	2. Hydraulic control flatbed and carriage arm,with hydraulic operation lever.
	3. Winch speed : 5m/min min.
	4. Flatbed working stroke: 2680mm
	5. Flatbed minimum tilt angle: 10°
	6. Carriage arm telescopic stroke: 1180mm
	7. The max effective length of the carriage arm: 1300mm



» Ⅲ.Product Details & Advantages:

The 5 ton flatbed wrecker upper body kits are critical equipment for road traffic rescue and accident handling. Their compact structure and comprehensive functionality enable rapid response to various vehicle breakdowns and accidents, making them widely used in complex scenarios such as highways, urban roads, and parking lots.



1. Comprehensive Structure and Versatile Functions

●The road wrecker truck's upper body is driven by a hydraulic system, driving the telescopic boom, pallet, and trailer frame to perform lifting, retracting, and rotating movements, allowing for flexible and precise operation.

●The pallet's sturdy and durable structure can accommodate vehicles of varying sizes and weights, meeting diverse rescue needs.

●The winch, combined with a wire rope, efficiently completes towing operations and enables rapid vehicle transfer. The entire system is rationally designed and easy to use.

2. High Safety and Reliable Performance

●Safety and stability are crucial in tow removal operations. The Flatbed Road Rescue Tow Truck Superstructure is equipped with a tow hook and wire rope traction system to securely secure the disabled vehicle, preventing it from slipping or tilting during towing.

●The support legs provide additional stability during operation, effectively preventing the vehicle from tipping over and ensuring the safety of both the operator and the vehicle. The hydraulic system features reliable locking and protection devices, ensuring stable performance even in demanding working environments.



3. Wide Application and Outstanding Efficiency

●The 5-ton flatbed wrecker upper body kit is suitable not only for roadside rescue of small cars, but also for accident clearance of medium and large vehicles, making it a very versatile tool.

●Its high efficiency and simple and quick operation enable rapid vehicle transfers on narrow roads, in heavy traffic, or in complex accident scenarios, effectively reducing traffic congestion and improving road accessibility.



•

•

•




Products--100% Customized Level One!

Transportation--100% Safety, Convenience, Efficient!

Services--7days + 24hours Safetify Service!



1.we can do the designs according to the your requirement .

2.we can offer you the high quality & reasionalble price

3.we can offer your a reliable after-sell service

4.we have skilled professinal design team

5.promptly delivery. any order is welcome.



CEEC factory also supply spare parts (original, OEM, and replacement) for all types of trucks and trailers
with discount and nice quality to ensure our customers's trucks and trailers being in good working conditions.
