Beiben 8000L offroad 4x4 water sprinkler tank truck

I. PRODUCT Overview

Beiben 4x4 all-wheel drive sprinkler truck is a sprinkler with four-wheel drive technology. Beiben 1929 water sprinkler truck produced based on Beiben factory and the functional characteristics of sprinkler trucks, and is suitable for a variety of complex road conditions and sprinkler operation needs. Beiben 1929 AWD water bowser has demonstrated excellent performance and stability in a variety of application scenarios with its excellent four-wheel drive technology and efficient sprinkler function. Beiben tanker truck is one of the indispensable and important tools in the fields of urban environmental sanitation, road maintenance and emergency rescue. The original Beiben 4x4 truck chassis with ND number ND1190ED3J6Z22, classical NG80B short cabin with no sleeper bed, 4x4 offroad drive model suitable for desert and very tough road condition. TOP 1 Chinese brand WEICHAI diesel engine WP10.290E32 model, 209KW / 290HP with emission 9726cc, FAST 9 shift manual gearbox with 9 forward and 2 reverse, special transfer gearbox for Beiben 4x4 offroad cesspool truck is VG1400, steering machine 8098, spring steel plate pieces is 10/8+6, customized tire 12.00R20 model with 6+1 units, including one spare tire, fuel tanker capacity 400L, 4800mm wheelbase with front axle capacity 7tons and rear axle capacity 13tons, customized white painting for Beiben NG80B truck cabin.

Beiben water tank truck is an efficient and practical sanitation vehicle for road cleaning and water spraying. Based on original Mercedes Benz technology BEIBEN 1929 model 4x4 offroad type chassis, mounted with 8000L water tanker, material Q235 carbon steel, with tanker and shell both 4mm thickness, TOP 1 Chinese brand WEILONG water pump, equipped with full sets water spraying system, including front water spraying nozzles, rear water spraying nozzles, also rear platform with water canon, top air control safety platform and fence.

(1) Beiben 1929 offroad 4x4 RHD 8000L water bowser tank truck Advanced Features:

(2) Working Principle for Beiben 4x4 Water Tank Truck

The Water tanker truck Beiben is a special vehicle for washing operations in urban roads, highways, squares, and other places, as well as municipal and landscaping watering operationsfor washing operations in urban roads, highways, squares, and other places, as well as municipal and landscaping watering operations. That type of water tanker truck adopted cargo truck chassis,and mounted with water tanker,equipped with high-efficiency water pump,also have the fuction of front flushing,rear spraying and water monitor for some emergency fire fighting work.

China North Benz Beibzn 1929 Water Spraying Truck are used in urban roads, large factories, military units, gardens and other units to clean the road surface, maintain hygiene, prevent dust, water, spray pesticides, etc., in order to achieve the effect of beautifying the environment. It can also be used for temporary emergency fire sprinkler, and each sprinkler truck is equipped with a dedicated firefighting interface. The engine drives the gearbox, and the power take-off installed on the gearbox drives the sprinkler pump. The sprinkler pump generates the main power and sprays the liquid inside the tank through the pipeline network. Self suction height: ≤ 7m, sprinkler width: ≥ 20m, maximum range: ≥ 28m; Adjustable in a cylindrical shape, with a range of ≥ 28m; It can also be adjusted to a mist shape with a range of ≥ 5m. Spray front and sprinkle back, with a duck shaped nozzle or round head nozzle installed in the front, a cylindricalsprinkler nozzle or showerhead nozzle installed in the back, and a working platform equipped with a high-pressure water cannon at the rear. The rear can also be equipped with 8 nozzles (optional). Water sprayers are generally used to flush the streets.

(3) Technical Specifications for Beiben 4x4 Sewage Suction Truck

Beiben 1929 RHD 4x4 Military Suction sewage vacuum tank truck is a new type of sanitation vehicle to collect, transfer and clean the transportation of sludge and sewage and avoid secondary pollution. Beiben vacuum pump truck can suction and discharge from itself, with fast working speed, large capacity and convenient transportation, suitable for the collection and transportation of feces, mud, crude oil and other liquid substances. Beiben sewage tanker truck using domestic technology leading suction suction car vacuum pump, large suction, long suction range, especially suitable for sewage sludge suction, loading and discharge, especially can suck sewage mud, silt, stone, brick and other large objects.

II. Product Detailed Features

Beiben water bowser truck, as a professionally manufactured sprinkler model, is known for its powerful driving ability and sprinkler function. Drive mode is military usage 4x4 all-wheel drive,  this driving mode can give the vehicle excellent stability and passability, so that the sprinkler can operate stably in complex and changeable road environments.

Four-wheel drive: The four-wheel drive system can automatically distribute torque to the front and rear wheels according to the state of the driving road to improve the driving ability and stability of the car. Whether on rugged mountain roads, muddy construction sites or slippery city streets, the Beiben 4x4 all-wheel drive sprinkler truck can show excellent driving performance.

Sprinkling function: The Beiben 4x4 water tanker truck is equipped with an efficient sprinkler system, including key components such as power take-off, water pump, water tank, pipes and valves. The sprinkler system can be flexibly adjusted according to the operation requirements to achieve different spraying effects and sprinkler widths.

Water Tank structure: The tank of the sprinkler truck is made of high-strength steel plate, and the shape is usually oval or square to ensure sufficient carrying capacity and durability. A partition is provided inside the tank to reduce the impact of the vehicle on the liquid in the tank during driving.

(2) Advanced features for Beiben 4x4 Water Tank Truck

Beiben 4x4 all-wheel drive, that is, Beiben 4x4 all-wheel drive model, the "4x4" here means that the vehicle has four wheels and all of them are drive wheels. All-wheel drive means that the engine output torque of the vehicle can be distributed to all wheels as needed to improve the vehicle's traction, passability and driving stability. Beiben 4x4 all-wheel drive models have better traction and passability in complex or harsh road conditions (such as mud, snow, rugged mountain roads, etc.) The four-wheel drive system can adjust the power distribution according to the road conditions, thereby maintaining the stability of the vehicle and reducing the risk of skidding and loss of control. Beiben 4x4 all-wheel drive models are not only suitable for urban roads, but also very suitable for off-road, exploration and other scenarios that require high passability and stability.
