ISUZU GIGA 25 ton refrigerated truck

ISUZU GIGA heavy duty freezer truck

ISUZU GIGA refrigerator van truck, ISUZU left hand drive model 6×4 chassis, FAST 12-shift manual gearbox, ISUZU 350HP diesel engine. Equipped with Carrier cooling unit for high performance, as for van capacity can be 5-25T optional.

  • Product Origin:

    China CEEC
  • Shipping Port:

    China Main Port
  • Lead Time:

    20 Days
  • Payment:

    T/T, West Union
contact now
ISUZU GIGA 10 wheeler freezer van

 Applications:

ISUZU refrigerated van (also called Refrigerated box truck ISUZU, ISUZU GIGA chiller lorry, ISUZU GIGA freezer truck, ISUZU GIGA refrigerator van truck, ISUZU GIGA refrigerated truck) is a van or truck designed to carry perishable freight as specific temperatures.


Refrigerator trucks can be ice-cooled, equipped with any one of a variety of mechanical refrigeration system powered by small displacement diesel engines, or utilize carbon dioxide as a cooling agent.


CEEC TRUCKS can supply reefer box trucks with capacity from 2Ton, 3.2Ton, 4Ton, 5Ton, 6.3Ton, 8Ton, 10Ton, 12Ton, 14Ton, 16Ton, 25Ton.


 Key Features:



---- ISUZU chassis, perfect performance

---- ISUZU technology engine option, super powerful, no overhaul within 100,000 km.

---- Refrigeration system brand can be optional.

---- Transportation temperature can be from +7°C, +2°C, -10°C, -15°C, -20°C, -25°C.



 Specifications:



  ISUZU GIGA freezer truck (25 Ton)

General

Vehicle Brand

CEEC TRUCKS

Chassis Brand

ISUZU

Overall Dimension

11900* 2600 * 3980 mm

GVW / Kerb Weight

25,000kg / 12,000kg

Cab

Cab Capacity

3 persons allowed

Air Conditioner

Heating/cooling air conditioner

Engine

Fuel Type

Diesel

Engine Brand

ISUZU

Power

350 HP (257 KW)

Displacement

9839 ml

Emission Standard

Euro 5

Chassis

Drive Type

6X4 (left hand drive)

Transmission

FAST 12-shift speed levers with 2 reverse

Wheelbase/No. of axle

3985+1370 mm / 3

Tire Specification

12.00R22.5

Tire Number

10 tires and 1 spare tire

Max Speed

90 km/h

Paint

Metallic paint

Superstructure

Body size

9600×2500×2500(mm)

Load Capacity

25 Tons

Panel Structure

Fiber glass sandwich polyurethane

Front/Side/Rear panel

Panel Thickness: 85mm

Roof/Floor panel

Panel Thickness: 105mm

Lights & Switch

Led, Water-proof, 12V/24V convertible

Lowest temperature

-5°C or -25

Equipment

Standard: Aluminum alloy flooring, rear doors.

Optional: 1. Hydraulic Taillift and Cargo Control System.

2. Side doors, side steps and ladders.

3. Different temperature area control.

4. Customized floor roller design for convenient working.



ISUZU freezer truck manufacturer
(Professional freezer truck manufacturer, high quality refrigerated trucks for sale)

CEEC TRUCKS is a premium freezer truck manufacturer and supplier. We can provide ISUZU freezer truck, HOWO refrigerated truck, FOTON chiller lorry, Dongfeng reefer truck, etc. The capacity of van can be 3-25 tons. Our refrigerator trucks are very popular in Southeast Asia, Middle East, Africa and South America because of the high quality and low price.

Equipped with famous domestic chassis such as ISUZU, Dongfeng, Foton, FAW, JAC, JMC, and Sinotruk

Equipped with famous refrigeration units, Thermo King & Carrier, & Guchen Super Snow refrigeration units.

Refrigerated truck body structure is sandwich structure: Fiberglass + PU + fiberglass. All the double surface sandwich polyurethane panel and door are 100mm thickness, the Fiberglass plate thickness is 2.5mm for the outer and inner skins; the polyurethane foam density is 45-50kg/m3. (All is the best material in China and have excellent insulation performance).

The hardware (door frame, hinge, lock, handle) are made of 304 stainless steel, and wrap angle are aluminum alloy.

Sandwich panel thickness can be changed according to customers’ requirements: 60mm, 80mm, and 100mm.




ISUZU GIGA refeer truck for export

ISUZU GIGA refrigerator truck for sale

CEEC TRUCKS is a leading manufacturer and exporter of refrigerated trucks in China. We possess over 10-year export experience of freezer trucks. We can ensure the fast delivery time and 12 months guarantee for our freezer lorry. Our refeer trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, etc.


---- Maximize save your sea freight.

---- Professional guidance on your importing documents.

---- Safety, Quickly, Timely



CEEC garbage compactor truck factory review


---- Service more than 60 countries.

----  Professional guidance on your importing documents.

----  CO, FORM E, FORM P, Pre-shipping Inspection...



 export documents
Successful Cases
inquiry now

    Please feel free to inquiry trucks from us; our experience sale manager will give the quotation within 12 hours
